Lockey Hydraulic Gate Closer TB100
Regular price
$62.18
Regular price
-30%
$88.82
Sale price
$62.18
Couldn't load pickup availability
Got questions? Talk to a product expert.
Lockey Hydraulic Gate Closer TB100 Turtle Back Slow Close fits most flush gate and frame arrangements where the gate weight is up to 150 lbs and width is no more than 54 inches. Both the travel and latching speeds are fully adjustable, ensuring gates close in a controlled manner. These closers are particularly suited to pool gates, garden gates, picket gates, barrier gates and lightweight doors (NON FIRE RATED).
No special skills are required to install the gate closes, as detailed step-by-step instructions are included. Overall dimensions 7-1/2" high, 13" wide, 2-1/2" deep. Fits Gates Up To 150 LBS And 54" Wide.
Features
Gently closes both small and large gates up to 125lbs.
Pushes gate closed
Adjustable closing speed
Can be installed on top, bottom or middle of gate
Recommended for pool, garden and barrier gates
Can be used on lightweight (non fire-rated) doors
Works best on gates with in-line/flush hinges
To retain product warranty & restrict gate opening angle, a gate stop must be installed
The LockeyUSA Turtle Back TB100 Hydraulic Gate closer must mount on the hinge side/pull side of the gate in order to push the gate closed. The TB100 works best if the gate has in-line/flush hinges flush with the gate post with 1″ or less gap.
Dimensions & Specifications
Dimensions: 7 1/2″ L x 13″ W x 2 1/2″ D
Mounting Bracket Dimensions: 3 1/4″ x 1 3/4″
Max. Gate Weight: 125 lbs.
Max. Gate Width: 54″
Max. Opening Angle: 90 degrees
Min. Operating Temperature: 10 degrees
Max. Operating Temperature: 110 degrees
Type of Gate Material: Vinyl, Wood, Steel, Chain Link
Closing/Latching Method: Hydraulic
Material: Steel
Finish: Powder-Coated
Color: Black
Hinge Arrangements: In-line/flush hinges
Opening Pressure: Variable, depending on gate size
Free Shipping Within Contiguous US.
- SKU LSGC TB100
Place your order by 2 PM and it will ship for next business day delivery in most cases. We utilize reliable 24-hour carrier services whenever available to help ensure your order arrives on time.
A minimum order of $99 is required. Orders meeting this minimum qualify for standard shipping rates. Additional charges may apply for deliveries to remote or hard-to-reach areas, as determined by the carrier.
Lockey Store does not handle product warranties directly. All warranties, if applicable, are provided and administered by the manufacturer.
Warranty terms, coverage, and claims are subject to the manufacturer’s policies. For warranty support, customers must contact the manufacturer directly with proof of purchase.
